SKT962
Skin tumor tissue array, set 2, non-overlapping with SKT961, 96 cores, 48 cases from normal, premalignant and cancer tissues with progressive grades and stages in duplicates
Specification
Data Sheet
TNM Grading
Downloads
Price
Size
Availability
$307
1 slide
In-Stock
A | |
B | |
C | |
D | |
E | |
F | |
G | |
H | |
TNM Classification : Malignant melanoma of skin
T- Primary tumor
TX - Primary tumor cannot be assessed
TO - No evicence of primary tumor
Tis - Melanoma in situ (Clark level I), (atypical melanocytic hyperplasia, severe melanocytic dysplasia, not an invasive malignant lesion)
T1 - Tumor 0.75 mm or less in thickness and invades the papillary dermis (Clark level II)
T2 - Tumor more than 0.75 mm but not more than 1.5 mm in thickness and or invades to the papillary-reticular dermis interface (Clark level III)
T3 Tumor more than 1.5 mm but not more than 4.0 mm in the thickness, and/or invades the reticular dermis (Clark level IV)
T3a - Tumor more than 1.5 mm but not more than 3.0 mm in thickness
T3b - Tumor more than 3.0 mm but not more than 4.0 mm in thickness
T4 - Tumor more than 4.0 mm in thickness, and/or invades subcutanesous tissue (Clark level V) and/or satellite(s) within 2 cm of the primary tumor
T4a - Tumor more than 4.0 mm in thickness and/or invades subcutanesous tissue
T4b - Satellite(s) within 2 cm of the primary tumor
Notes: in case of discrepancy between tumor thickness and level, the T category is based on the less favorable finding.
N - Regional lymph nodes
NX - Regional lymph nodes cannot be assessed NO - No regional lymph node metastasis
N1 - Metastasis 3 cm or less in greatest dimension in any regional lymph node(s)
N2 - Metastasis more than 3 cm in greatest dimension in any regional lymph node(s) and/or in-transit metastasis
N2a - Metastasis more than 3 cm in greatest dimension in any regional lymph node(s)
N2b - In-transit metastasis
N2c - Both
M - Distant metastasis
MX - Distant metastasis cannot be assessed MO - No distant metastasis
M1 - Distant metastasis
M1a - Metastasis in skin or subcutaneous tissue or lymph node(s) beyond the regional lymph nodes
M1b - Visceral metastasis
Human
48
96
1.5mm
4um
8
12
Paraffin
Notes:
All tissues were fixed in 10% neutral buffered formalin for 24 hours and processed using identical SOPs. Sections were picked onto Superfrost Plus or Startfrost Adhesive slides. They all have a guaranteed six month shelf-life at 4C from the date of shipment. Additional cores not listed are orientation markers and have no data. There maybe <5% core loss per slide but the core retention rate should be >90%.
Bake at 60C for 30 minutes before use. If antigen retrieving is needed, it is always a good idea to start with a protocol with weak to mild strength. Please check our TNM guide as a reference. For IHC related information on products that provide them, please contact us at info@pantomics.com for the most up-to-date information.
For research use only. Designed for IHC or ISH based protein or RNA tissue profiling in evolution and progression of skin tumors.
ARRAY POSITION | IMAGE | SEX | AGE | ANATOMIC SITE | PATHOLOGY | GRADE | STAGE (TNM) |
|---|---|---|---|---|---|---|---|
A01 | M | 43 | Skin, scalp | Normal | |||
A02 | F | 43 | Skin | Normal | |||
A03 | F | 53 | Skin | Scar | |||
A04 | M | 26 | Skin, scalp | Warts | |||
A05 | M | 40 | Skin | Warts | |||
A06 | F | 71 | Skin | Seborrheic keratosis | |||
A07 | M | 76 | Skin | Seborrheic keratosis | |||
A08 | M | 38 | Scrotum | Condyloma acuminata | |||
A09 | M | 32 | Skin, penis | Papilloma | |||
A10 | F | 80 | Skin | Papilloma | |||
A11 | F | 85 | Skin | Papilloma | |||
A12 | M | 12 | Skin | Keratoacanthoma | |||
B01 | M | 43 | Skin, scalp | Normal | |||
B02 | F | 43 | Skin | Normal | |||
B03 | F | 53 | Skin | Scar | |||
B04 | M | 26 | Skin, scalp | Warts | |||
B05 | M | 40 | Skin | Warts | |||
B06 | F | 71 | Skin | Seborrheic keratosis | |||
B07 | M | 76 | Skin | Seborrheic keratosis | |||
B08 | M | 38 | Scrotum | Condyloma acuminata | |||
B09 | M | 32 | Skin, penis | Papilloma | |||
B10 | F | 80 | Skin | Papilloma | |||
B11 | F | 85 | Skin | Papilloma | |||
B12 | M | 12 | Skin | Keratoacanthoma | |||
C01 | F | 53 | Skin, nose | Basal cell carcinoma | |||
C02 | M | 24 | Skin, right lower eyelid | Basal cell carcinoma | |||
C03 | M | 56 | Skin, nose | Basal cell carcinoma | |||
C04 | M | 54 | Skin | Basal cell carcinoma | |||
C05 | M | 76 | Skin, nose | Basal cell carcinoma | |||
C06 | F | 70 | Skin | Basal cell carcinoma | |||
C07 | M | 65 | Head and neck, upper lip | Basal cell carcinoma | |||
C08 | F | 62 | Skin, chest, large sweat gland | Syringocarcinoma | |||
C09 | M | 36 | Skin | Squamous cell carcinoma | I | T1N0M0 | |
C10 | M | 78 | Skin, scalp | Squamous cell carcinoma | I | T1N0M0 | |
C11 | M | 56 | Skin, scalp | Squamous cell carcinoma | I | T1N0M0 | |
C12 | M | 77 | Skin, scalp | Squamous cell carcinoma | I | T1N0M0 | |
D01 | F | 53 | Skin, nose | Basal cell carcinoma | |||
D02 | M | 24 | Skin, right lower eyelid | Basal cell carcinoma | |||
D03 | M | 56 | Skin, nose | Basal cell carcinoma | |||
D04 | M | 54 | Skin | Basal cell carcinoma | |||
D05 | M | 76 | Skin, nose | Basal cell carcinoma | |||
D06 | F | 70 | Skin | Basal cell carcinoma | |||
D07 | M | 65 | Head and neck, upper lip | Basal cell carcinoma | |||
D08 | F | 62 | Skin, chest, large sweat gland | Syringocarcinoma | |||
D09 | M | 36 | Skin | Squamous cell carcinoma | I | T1N0M0 | |
D10 | M | 78 | Skin, scalp | Squamous cell carcinoma | I | T1N0M0 | |
D11 | M | 56 | Skin, scalp | Squamous cell carcinoma | I | T1N0M0 | |
D12 | M | 77 | Skin, scalp | Squamous cell carcinoma | I | T1N0M0 | |
E01 | M | 47 | Skin, scalp | Squamous cell carcinoma | II | T2N0M0 | |
E02 | M | 67 | Skin | Squamous cell carcinoma | II | T1N0M0 | |
E03 | F | 57 | Skin, vulva | Squamous cell carcinoma | II | T2N1M0 | |
E04 | M | 80 | Skin | Squamous cell carcinoma | II | T1N0M0 | |
E05 | M | 45 | Skin, neck | Squamous cell carcinoma | III | T2N0M0 | |
E06 | F | 83 | Skin | Squamous cell carcinoma | III | T1N0M0 | |
E07 | F | 58 | Skin, scalp | Squamous cell carcinoma | III | T1N0M0 | |
E08 | F | 18 | Skin | Compound nevus | |||
E09 | M | 9 | Skin | Compound nevus | |||
E10 | M | 88 | Skin | Junctional nevus | |||
E11 | F | 60 | Skin, toe | Melanoma | Radial | ||
E12 | M | 11 | Skin, left foot | Melanoma | Radial | ||
F01 | M | 47 | Skin, scalp | Squamous cell carcinoma | II | T2N0M0 | |
F02 | M | 67 | Skin | Squamous cell carcinoma | II | T1N0M0 | |
F03 | F | 57 | Skin, vulva | Squamous cell carcinoma | II | T2N1M0 | |
F04 | M | 80 | Skin | Squamous cell carcinoma | II | T1N0M0 | |
F05 | M | 45 | Skin, neck | Squamous cell carcinoma | III | T2N0M0 | |
F06 | F | 83 | Skin | Squamous cell carcinoma | III | T1N0M0 | |
F07 | F | 58 | Skin, scalp | Squamous cell carcinoma | III | T1N0M0 | |
F08 | F | 18 | Skin | Compound nevus | |||
F09 | M | 9 | Skin | Compound nevus | |||
F10 | M | 88 | Skin | Junctional nevus | |||
F11 | F | 60 | Skin, toe | Melanoma | Radial | ||
F12 | M | 11 | Skin, left foot | Melanoma | Radial | ||
G01 | M | 49 | Skin, left foot | Melanoma | Radial | ||
G02 | F | 72 | Skin, right foot | Melanoma | Radial | ||
G03 | M | 68 | Skin, right foot | Melanoma | Radial | ||
G04 | F | 54 | Anus | Melanoma | Vertical | ||
G05 | F | 59 | Skin, vulva | Melanoma | Vertical | ||
G06 | M | 24 | Skin, right foot | Melanoma | Vertical | ||
G07 | F | 82 | Anus | Melanoma | Vertical | ||
G08 | M | 50 | Lymph node | Metastatic melanoma | |||
G09 | F | 76 | Lymph node, inguinal | Metastatic melanoma | |||
G10 | M | 43 | Lymph node | Metastatic melanoma | |||
G11 | F | 38 | Lymph node | Metastatic melanoma | |||
G12 | F | 79 | Lymph node | Metastatic melanoma | |||
H01 | M | 49 | Skin, left foot | Melanoma | Radial | ||
H02 | F | 72 | Skin, right foot | Melanoma | Radial | ||
H03 | M | 68 | Skin, right foot | Melanoma | Radial | ||
H04 | F | 54 | Anus | Melanoma | Vertical | ||
H05 | F | 59 | Skin, vulva | Melanoma | Vertical | ||
H06 | M | 24 | Skin, right foot | Melanoma | Vertical | ||
H07 | F | 82 | Anus | Melanoma | Vertical | ||
H08 | M | 50 | Lymph node | Metastatic melanoma | |||
H09 | F | 76 | Lymph node, inguinal | Metastatic melanoma | |||
H10 | M | 43 | Lymph node | Metastatic melanoma | |||
H11 | F | 38 | Lymph node | Metastatic melanoma | |||
H12 | F | 79 | Lymph node | Metastatic melanoma | |||
