NPC961
Nasopharyngeal carcinoma tissue array, set 1, non-overlapping with NPC111, NPC481, NPC962, NPC1501, NPC1502 or NPC1503, containing 31 cases of primary tumors with paired normal tissues, 17 cases of lymph node metastatic tumors and 12 cases of normal/reactive nasopharyngeal mucosal tissues.
Specification
Data Sheet
TNM Grading
Downloads
Price
Size
Availability
Inquire
1 slide
In-Stock
A | |
B | |
C | |
D | |
E | |
F | |
G | |
H | |
TNM Classification : Nasopharygeal carcinoma
T - Primary Tumor
TX - Primary tumor cannot be assessed
T0 - No evidence of primary tumor
Tis - Carcinoma in situ
T1 - Tumor confined to nasopharynx
T2 - Tumor estends to soft tissue of oropharynx and/or nasal fossa
T2a – without parapharyngeal extension
T2b – with parapharyngeal extension
T3 - Tumor invades bony structures and/or paranasal sinuses
T4 - Tumor with intracranial extension and/or involvement of cranial nerves, infratemporal fossa, hypopharynx, or orbit
N - Regional Lymph nodes
NX - Reginal lymph nodes cannot be assessed
N0 - No regional lymph node metastasis
N1 - Unilateral metastasis in lymph node(s), 6cm or less in greatest dimension, above supraclavicular fossa
N2 - Bilateral metastasis in lymph node(s), 6cm or less in greatest dimension, above supraclavicular fossa
N3 - Metastasis in lymph node(s)
(a) greater than 6cm in dimension
(b) in the supraclavicular
M - Distant Metastasis
MX - Distant metastasis cannot be assessed
M0 - No distant metasissis
M1 - Distant metastasis
Human
>50
96
1.5mm
4um
8
12
Paraffin
Notes:
All tissues were fixed in 10% neutral buffered formalin for 24 hours and processed using identical SOPs. Sections were picked onto Superfrost Plus or Startfrost Adhesive slides. They all have a guaranteed six month shelf-life at 4C from the date of shipment. Additional cores not listed are orientation markers and have no data. There maybe <5% core loss per slide but the core retention rate should be >90%.
Bake at 60C for 30 minutes before use. If antigen retrieving is needed, it is always a good idea to start with a protocol with weak to mild strength. Please check our TNM guide as a reference. For IHC related information on products that provide them, please contact us at info@pantomics.com for the most up-to-date information.
For research use only. Designed for comparative IHC or ISH based protein or RNA tissue profiling in paired normal, primary and metastatic tumor tissues from multiple nasopharyngeal carcinoma patients.
ARRAY POSITION | IMAGE | SEX | AGE | ANATOMIC SITE | PATHOLOGY | GRADE | STAGE (TNM) |
|---|---|---|---|---|---|---|---|
A01 | M | 44 | Head and neck, nasopharynx | Squamous cell carcinoma | II | T1N0M0 | |
A02 | M | 35 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N2M0 | |
A03 | M | 37 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T3N0N0 | |
A04 | M | 46 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N1M0 | |
A05 | M | 39 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
A06 | M | 49 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
A07 | M | 40 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
A08 | F | 26 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N2M0 | |
A09 | M | 56 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N2M0 | |
A10 | M | 50 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T3N1M0 | |
A11 | F | 54 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T3N2M0 | |
A12 | M | 36 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N2M0 | |
B01 | M | 44 | Head and neck, nasopharynx | Adjacent mucosa of A1 | |||
B02 | M | 35 | Head and neck, nasopharynx | Adjacent mucosa of A2 | |||
B03 | M | 37 | Head and neck, nasopharynx | Adjacent mucosa of A3 | |||
B04 | M | 46 | Head and neck, nasopharynx | Adjacent mucosa of A4 | |||
B05 | M | 39 | Head and neck, nasopharynx | Adjacent mucosa of A5 | |||
B06 | M | 49 | Head and neck, nasopharynx | Adjacent mucosa of A6 | |||
B07 | M | 40 | Head and neck, nasopharynx | Adjacent mucosa of A7 | |||
B08 | F | 26 | Head and neck, nasopharynx | Adjacent mucosa of A8 | |||
B09 | M | 56 | Head and neck, nasopharynx | Adjacent mucosa of A9 | |||
B10 | M | 50 | Head and neck, nasopharynx | Adjacent mucosa of A10 | |||
B11 | F | 54 | Head and neck, nasopharynx | Adjacent mucosa of A11 | |||
B12 | M | 36 | Head and neck, nasopharynx | Adjacent mucosa of A12 | |||
C01 | M | 50 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N1M0 | |
C02 | M | 35 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N1M0 | |
C03 | M | 42 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T3N1M0 | |
C04 | M | 0 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N0M0 | |
C05 | M | 0 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N1M0 | |
C06 | M | 37 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T3N2M0 | |
C07 | M | 48 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T4N1M1 | |
C08 | F | 35 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T4N0M0 | |
C09 | F | 40 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
C10 | M | 40 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T4N0M0 | |
C11 | F | 57 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T4N2M0 | |
C12 | M | 35 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N1M0 | |
D01 | M | 50 | Head and neck, nasopharynx | Adjacent mucosa of C1 | |||
D02 | M | 35 | Head and neck, nasopharynx | Adjacent mucosa of C2 | |||
D03 | M | 42 | Head and neck, nasopharynx | Adjacent mucosa of C3 | |||
D04 | M | 0 | Head and neck, nasopharynx | Adjacent mucosa of C4 | |||
D05 | M | 0 | Head and neck, nasopharynx | Adjacent mucosa of C5 | |||
D06 | M | 37 | Head and neck, nasopharynx | Adjacent mucosa of C6 | |||
D07 | M | 48 | Head and neck, nasopharynx | Adjacent mucosa of C7 | |||
D08 | F | 35 | Head and neck, nasopharynx | Adjacent mucosa of C8 | |||
D09 | F | 40 | Head and neck, nasopharynx | Adjacent mucosa of C9 | |||
D10 | M | 40 | Head and neck, nasopharynx | Adjacent mucosa of C10 | |||
D11 | F | 57 | Head and neck, nasopharynx | Adjacent mucosa of C11 | |||
D12 | M | 35 | Head and neck, nasopharynx | Adjacent mucosa of C12 | |||
E01 | M | 35 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N2M0 | |
E02 | M | 51 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E03 | M | 31 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N1M1 | |
E04 | M | 50 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T2N2M0 | |
E05 | M | 45 | Head and neck, nasopharynx | Squamous cell carcinoma | III | T1N1M0 | |
E06 | M | 46 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E07 | M | 50 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E08 | M | 41 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E09 | M | 51 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E10 | M | 32 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E11 | M | 40 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
E12 | M | 48 | Head and neck, nasopharynx | Squamous cell carcinoma | III | ||
F01 | M | 35 | Head and neck, nasopharynx | Adjacent mucosa of E1 | |||
F02 | M | 51 | Head and neck, nasopharynx | Adjacent mucosa of E2 | |||
F03 | M | 31 | Head and neck, nasopharynx | Adjacent mucosa of E3 | |||
F04 | null | 50 | Head and neck, nasopharynx | Adjacent mucosa of E4 | |||
F05 | M | 45 | Head and neck, nasopharynx | Adjacent mucosa of E5 | |||
F06 | M | 46 | Head and neck, nasopharynx | Adjacent mucosa of E6 | |||
F07 | M | 50 | Head and neck, nasopharynx | Adjacent mucosa of E7 | |||
F08 | M | 41 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
F09 | M | 51 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
F10 | M | 32 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
F11 | M | 40 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
F12 | M | 48 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G01 | M | 35 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G02 | M | 51 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G03 | M | 31 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G04 | null | 50 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G05 | M | 45 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G06 | M | 46 | Liver | Metastatic nasopharygeal carcinoma, NPC | |||
G07 | M | 50 | Lymph node | Metastatic nasopharygeal carcinoma, NPC | |||
G08 | M | 41 | Head and neck, nasopharynx | Normal mucosa | |||
G09 | M | 51 | Head and neck, nasopharynx | Normal mucosa | |||
G10 | M | 32 | Head and neck, nasopharynx | Normal mucosa | |||
G11 | M | 40 | Head and neck, nasopharynx | Normal mucosa | |||
G12 | M | 48 | Head and neck, nasopharynx | Normal mucosa | |||
H01 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H02 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H03 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H04 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H05 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H06 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H07 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H08 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H09 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H10 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H11 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
H12 | null | 0 | Head and neck, nasopharynx | Normal mucosa | |||
