KIC1503
Kidney cancer tissue array, set 3, non-overlapping with KIC1501 or KIC1502, containing 75 cases in 150 cores with tumor paired with normal tissues from the same patients with grading and TNM staging data.
Specification
Data Sheet
TNM Grading
Downloads
Price
Size
Availability
$307
1 slide
In-Stock
A | |
B | |
C | |
D | |
E | |
F | |
G | |
H | |
I | |
J | |
TNM Classification : Kidney carcinoma
T- Primary tumor
TX - Primary tumor cannot be assessed
TO - No evidence of primary tumor
T1 - Tumor 7.0 cm or less in greatest dimension, limited to the kidney
T2 - Tumor more than 7. 0 cm, limited to the kidney
T3 - Tumor extends into major veins or invades adrenal gland or perinephric tissue but not beyond Gerota fascia
T4 - Tumor invades beyond Gerota fascia
N - Regional lymph nodes
NX - Regional lymph nodes cannot be assessed
NO - No regional lymph node metastasis
N1 - Metastasis in a single regional lymph node
N2 - Metastasis in more than one regional lymph nodes
M - Distant metastasis
MX - Distant metastasis cannot be assessed
MO - No distant metastasis
M1 - Distant metastasis
Human
75
150
1.1mm
4um
10
15
Paraffin
Notes:
All tissues were fixed in 10% neutral buffered formalin for 24 hours and processed using identical SOPs. Sections were picked onto Superfrost Plus or Startfrost Adhesive slides. They all have a guaranteed six month shelf-life at 4C from the date of shipment. Additional cores not listed are orientation markers and have no data. There maybe <5% core loss per slide but the core retention rate should be >90%.
Bake at 60C for 30 minutes before use. If antigen retrieving is needed, it is always a good idea to start with a protocol with weak to mild strength. Please check our TNM guide as a reference. For IHC related information on products that provide them, please contact us at info@pantomics.com for the most up-to-date information.
For research use only. Designed for normal vs cancer IHC or ISH based protein or RNA tissue profiling in kidney cancers.
ARRAY POSITION | IMAGE | SEX | AGE | ANATOMIC SITE | PATHOLOGY | GRADE | STAGE (TNM) |
|---|---|---|---|---|---|---|---|
A01 | M | 43 | Kidney | Granular cell carcinoma | T1N0M0 | ||
A02 | F | 64 | Kidney | Clear cell carcinoma | T1N0M0 | ||
A03 | F | 61 | Kidney | Squamous cell carcinoma | I | T1N0M0 | |
A04 | M | 77 | Kidney | Mixed renal cell and squamous cell carcinoma | T1N2M0 | ||
A05 | M | 46 | Kidney | Clear cell carcinoma | T1N0M0 | ||
A06 | M | 45 | Kidney | Clear cell carcinoma | T1N0M0 | ||
A07 | M | 56 | Kidney | Clear cell carcinoma | T1N0M0 | ||
A08 | F | 34 | Kidney | Clear cell carcinoma | T1N1M0 | ||
A09 | M | 48 | Kidney | Clear cell carcinoma | T1N0M0 | ||
A10 | M | 53 | Kidney | Transitional cell carcinoma | II | T1N0M0 | |
A11 | M | 36 | Kidney | Granular cell carcinoma | T1N0M0 | ||
A12 | M | 63 | Kidney | Granular cell carcinoma | T1N0M0 | ||
A13 | M | 46 | Kidney | Granular cell carcinoma | T1N0M0 | ||
A14 | M | 61 | Kidney | Clear cell carcinoma | T1N0M0 | ||
A15 | M | 78 | Kidney | Clear cell carcinoma | T1N0M0 | ||
B01 | M | 43 | Kidney | Uninvolved kidney tissue of A01 | |||
B02 | F | 64 | Kidney | Uninvolved kidney tissue of A02 | |||
B03 | F | 61 | Kidney | Uninvolved kidney tissue of A03 | |||
B04 | M | 77 | Kidney | Uninvolved kidney tissue of A04 | |||
B05 | M | 46 | Kidney | Uninvolved kidney tissue of A05 | |||
B06 | M | 45 | Kidney | Uninvolved kidney tissue of A06 | |||
B07 | M | 56 | Kidney | Uninvolved kidney tissue of A07 | |||
B08 | F | 34 | Kidney | Uninvolved kidney tissue of A08 | |||
B09 | M | 48 | Kidney | Uninvolved kidney tissue of A09 | |||
B10 | M | 53 | Kidney | Uninvolved kidney tissue of A10 | |||
B11 | M | 36 | Kidney | Uninvolved kidney tissue of A11 | |||
B12 | M | 63 | Kidney | Uninvolved kidney tissue of A12 | |||
B13 | M | 46 | Kidney | Uninvolved kidney tissue of A13 | |||
B14 | M | 61 | Kidney | Uninvolved kidney tissue of A14 | |||
B15 | M | 78 | Kidney | Uninvolved kidney tissue of A15 | |||
C01 | F | 44 | Kidney | Clear cell carcinoma | T1N0M0 | ||
C02 | F | 42 | Kidney | Transitional cell carcinoma | T1N0M0 | ||
C03 | M | 54 | Kidney | Clear cell carcinoma | T3N0M0 | ||
C04 | F | 48 | Kidney | Clear cell carcinoma | III | T2N0M0 | |
C05 | F | 66 | Kidney | Transitional cell carcinoma | II | T2N0M0 | |
C06 | F | 36 | Kidney | Clear cell carcinoma | T2N2M0 | ||
C07 | M | 49 | Kidney | Clear cell carcinoma | T2N0M0 | ||
C08 | M | 61 | Kidney | Squamous cell carcinoma | I | T2N0M0 | |
C09 | M | 58 | Kidney | Clear cell carcinoma | T1N0M0 | ||
C10 | M | 63 | Kidney | Clear cell carcinoma | T1N0M0 | ||
C11 | M | 66 | Kidney | Transitional cell carcinoma | II | T3N0M0 | |
C12 | M | 45 | Kidney | Granular cell carcinoma? | T2N0M0 | ||
C13 | M | 44 | Kidney | Transitional cell carcinoma | T1N0M0 | ||
C14 | M | 58 | Kidney | Clear cell carcinoma | T2N0M0 | ||
C15 | M | 35 | Kidney | Clear cell carcinoma | T2N0M0 | ||
D01 | F | 44 | Kidney | Uninvolved kidney tissue of C01 | |||
D02 | F | 42 | Kidney | Uninvolved kidney tissue of C02 | |||
D03 | M | 54 | Kidney | Uninvolved kidney tissue of C03 | |||
D04 | F | 48 | Kidney | Uninvolved kidney tissue of C04 | |||
D05 | F | 66 | Kidney | Uninvolved kidney tissue of C05 | |||
D06 | F | 36 | Kidney | Uninvolved kidney tissue of C06 | |||
D07 | M | 49 | Kidney | Uninvolved kidney tissue of C07 | |||
D08 | M | 61 | Kidney | Uninvolved kidney tissue of C08 | |||
D09 | M | 58 | Kidney | Uninvolved kidney tissue of C09 | |||
D10 | M | 63 | Kidney | Uninvolved kidney tissue of C10 | |||
D11 | M | 66 | Kidney | Uninvolved kidney tissue of C11 | |||
D12 | M | 45 | Kidney | Uninvolved kidney tissue of C12 | |||
D13 | M | 44 | Kidney | Uninvolved kidney tissue of C13 | |||
D14 | M | 58 | Kidney | Uninvolved kidney tissue of C14 | |||
D15 | M | 35 | Kidney | Uninvolved kidney tissue of C15 | |||
E01 | M | 61 | Kidney | Clear cell carcinoma | T2N0M0 | ||
E02 | M | 43 | Kidney | Chromophobe renal cell carcinoma | T2N0M0 | ||
E03 | F | 82 | Kidney | Chromophobe renal cell carcinoma | T2N0M0 | ||
E04 | M | 70 | Kidney | Eosinophilic renal cell carcinoma | T1N0M0 | ||
E05 | M | 68 | Kidney | Clear cell carcinoma | T2N0M0 | ||
E06 | F | 48 | Kidney | Granular cell carcinoma | T2N0M0 | ||
E07 | M | 48 | Kidney | Transitional cell carcinoma | II | T2N0M0 | |
E08 | F | 46 | Kidney | Squamous cell carcinoma | II | T2N0M0 | |
E09 | M | 72 | Kidney | Transitional cell carcinoma | II | T1N0M0 | |
E10 | F | 67 | Kidney | Transitional cell carcinoma | III | T1N0M1 | |
E11 | M | 45 | Kidney | Chromophobe renal cell carcinoma | T1N0M2 | ||
E12 | M | 54 | Kidney | Clear cell carcinoma | T2N0M0 | ||
E13 | F | 48 | Kidney | Transitional cell carcinoma | III | T1N0M0 | |
E14 | M | 21 | Kidney | Clear cell carcinoma | T2N0M0 | ||
E15 | M | 56 | Kidney | Granular cell carcinoma | T1N0M0 | ||
F01 | M | 61 | Kidney | Uninvolved kidney tissue of E01 | |||
F02 | M | 43 | Kidney | Uninvolved kidney tissue of E02 | |||
F03 | F | 82 | Kidney | Uninvolved kidney tissue of E03 | |||
F04 | M | 70 | Kidney | Uninvolved kidney tissue of E04 | |||
F05 | M | 68 | Kidney | Uninvolved kidney tissue of E05 | |||
F06 | F | 48 | Kidney | Uninvolved kidney tissue of E06 | |||
F07 | M | 48 | Kidney | Uninvolved kidney tissue of E07 | |||
F08 | F | 46 | Kidney | Uninvolved kidney tissue of E08 | |||
F09 | M | 72 | Kidney | Uninvolved kidney tissue of E09 | |||
F10 | F | 67 | Kidney | Uninvolved kidney tissue of E10 | |||
F11 | M | 45 | Kidney | Uninvolved kidney tissue of E11 | |||
F12 | M | 54 | Kidney | Uninvolved kidney tissue of E12 | |||
F13 | F | 48 | Kidney | Uninvolved kidney tissue of E13 | |||
F14 | M | 21 | Kidney | Uninvolved kidney tissue of E14 | |||
F15 | M | 56 | Kidney | Uninvolved kidney tissue of E15 | |||
G01 | M | 61 | Kidney | Squamous cell carcinoma | II | T2N1M0 | |
G02 | M | 40 | Kidney | Clear cell carcinoma | T1N0M0 | ||
G03 | M | 53 | Kidney | Papillary renal cell carcinoma | T1N0M0 | ||
G04 | F | 53 | Kidney | Transitional cell carcinoma | I | T3N0M0 | |
G05 | F | 20 | Kidney | Clear cell carcinoma | T1N0M0 | ||
G06 | M | 71 | Kidney | Clear cell carcinoma | T1N0M0 | ||
G07 | M | 60 | Kidney | Clear cell carcinoma | T2N0M0 | ||
G08 | M | 70 | Kidney | Squamous cell carcinoma | I | T3N0M0 | |
G09 | F | 65 | Kidney | Clear cell carcinoma | II~III | T1N0M0 | |
G10 | M | 53 | Kidney | Chromophobe renal cell carcinoma | T1N0M0 | ||
G11 | M | 67 | Kidney | Clear cell carcinoma | T1N0M0 | ||
G12 | F | 40 | Kidney | Clear cell carcinoma | T1N0M0 | ||
G13 | M | 65 | Kidney | Granular cell carcinoma | T1N0M0 | ||
G14 | M | 40 | Kidney | Clear cell carcinoma | II | T3N0M0 | |
G15 | M | 50 | Kidney | Papillary renal cell carcinoma | T1N0M0 | ||
H01 | M | 61 | Kidney | Uninvolved kidney tissue of G01 | |||
H02 | M | 40 | Kidney | Uninvolved kidney tissue of G02 | |||
H03 | M | 53 | Kidney | Uninvolved kidney tissue of G03 | |||
H04 | F | 53 | Kidney | Uninvolved kidney tissue of G04 | |||
H05 | F | 20 | Kidney | Uninvolved kidney tissue of G05 | |||
H06 | M | 71 | Kidney | Uninvolved kidney tissue of G06 | |||
H07 | M | 60 | Kidney | Uninvolved kidney tissue of G07 | |||
H08 | M | 70 | Kidney | Uninvolved kidney tissue of G08 | |||
H09 | F | 65 | Kidney | Uninvolved kidney tissue of G09 | |||
H10 | M | 53 | Kidney | Uninvolved kidney tissue of G10 | |||
H11 | M | 67 | Kidney | Uninvolved kidney tissue of G11 | |||
H12 | F | 40 | Kidney | Uninvolved kidney tissue of G12 | |||
H13 | M | 65 | Kidney | Uninvolved kidney tissue of G13 | |||
H14 | M | 40 | Kidney | Uninvolved kidney tissue of G14 | |||
H15 | M | 50 | Kidney | Uninvolved kidney tissue of G15 | |||
I01 | M | 73 | Kidney | Clear cell carcinoma | II | T2N0M0 | |
I02 | M | 53 | Kidney | Chromophobe renal cell carcinoma | T1N0M0 | ||
I03 | F | 67 | Kidney | Transitional cell carcinoma | I~II | T1N0M0 | |
I04 | M | 68 | Kidney | Clear cell carcinoma | T2N0M0 | ||
I05 | M | 50 | Kidney | Clear cell carcinoma | T1N0M0 | ||
I06 | M | 50 | Kidney | Clear cell carcinoma | T2N0M0 | ||
I07 | M | 40 | Kidney | Clear cell carcinoma | T1N0M0 | ||
I08 | F | 52 | Kidney | Chromophobe renal cell carcinoma | T2N0M0 | ||
I09 | F | 56 | Kidney | Clear cell carcinoma | T1N0M0 | ||
I10 | M | 64 | Kidney | Clear cell carcinoma | T1N0M0 | ||
I11 | M | 52 | Kidney | Papillary renal cell carcinoma | T1N0M0 | ||
I12 | F | 59 | Kidney | Clear cell carcinoma | T2N0M0 | ||
I13 | M | 40 | Kidney | Clear cell carcinoma | T1N0M0 | ||
I14 | M | 65 | Kidney | Transitional cell carcinoma | T1N0M0 | ||
I15 | F | 42 | Kidney | Chromophobe renal cell carcinoma | T2N0M0 | ||
J01 | M | 73 | Kidney | Uninvolved kidney tissue of I01 | |||
J02 | M | 53 | Kidney | Uninvolved kidney tissue of I02 | |||
J03 | F | 67 | Kidney | Uninvolved kidney tissue of I03 | |||
J04 | M | 68 | Kidney | Uninvolved kidney tissue of I04 | |||
J05 | M | 50 | Kidney | Uninvolved kidney tissue of I05 | |||
J06 | M | 50 | Kidney | Uninvolved kidney tissue of I06 | |||
J07 | M | 40 | Kidney | Uninvolved kidney tissue of I07 | |||
J08 | F | 52 | Kidney | Uninvolved kidney tissue of I08 | |||
J09 | F | 56 | Kidney | Uninvolved kidney tissue of I09 | |||
J10 | M | 64 | Kidney | Uninvolved kidney tissue of I10 | |||
J11 | M | 52 | Kidney | Uninvolved kidney tissue of I11 | |||
J12 | F | 59 | Kidney | Uninvolved kidney tissue of I12 | |||
J13 | M | 40 | Kidney | Uninvolved kidney tissue of I13 | |||
J14 | M | 65 | Kidney | Uninvolved kidney tissue of I14 | |||
J15 | F | 42 | Kidney | Uninvolved kidney tissue of I15 | |||
