LVC1531
Liver cancer tissue array, set 1, 51 cases, 153 cores, one normal paired with two tumor tissue cores from each patient with grading and TNM staging data.
Specification
Data Sheet
TNM Grading
Downloads
Price
Size
Availability
$307
1 slide
In-Stock
A | |
B | |
C | |
D | |
E | |
F | |
G | |
H | |
I | |
TNM Classification : Liver carcinoma
T- Primary tumor
TX - Primary tumor cannot be assessed
TO - No evidence of primary tumor
T1 - Solitary tumor without vascular invasion
T2 - Solitary tumor with vascular invasion or multiple tumors none larger than 5cm
T3 - Multiple tumors more than 5 cm, or tumor involving a major branch of the portal or hepatic vein(s)
T4 - Tumor(s) with direct invasion of adjacent organs other than the gallbladder or with perforation of visceral peritoneum
N - Regional lymph nodes
NX - Regional lymph nodes cannot be assessed
NO - No regional lymph node metastasis
N1 - Regional lymph node metastasis
M - Distant metastasis
MX - Distant metastasis cannot be assessed
MO - No distant metastasis
M1 - Distant metastasis
Human
51
153
1.1mm
4um
9
17
Paraffin
Notes:
All tissues were fixed in 10% neutral buffered formalin for 24 hours and processed using identical SOPs. Sections were picked onto Superfrost Plus or Startfrost Adhesive slides. They all have a guaranteed six month shelf-life at 4C from the date of shipment. Additional cores not listed are orientation markers and have no data. There maybe <5% core loss per slide but the core retention rate should be >90%.
Bake at 60C for 30 minutes before use. If antigen retrieving is needed, it is always a good idea to start with a protocol with weak to mild strength. Please check our TNM guide as a reference. For IHC related information on products that provide them, please contact us at info@pantomics.com for the most up-to-date information.
For research use only. Designed for normal vs cancer IHC or ISH based protein or RNA tissue profiling in liver cancers.
ARRAY POSITION | IMAGE | SEX | AGE | ANATOMIC SITE | PATHOLOGY | GRADE | STAGE (TNM) |
|---|---|---|---|---|---|---|---|
A01 | M | 48 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
A02 | M | 62 | Liver | Hepatocellular carcinoma | I | T2N0M0 | |
A03 | F | 42 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
A04 | M | 52 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A05 | M | 55 | Liver | Hepatocellular carcinoma | I | T2N0M0 | |
A06 | M | 45 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
A07 | M | 38 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
A08 | M | 55 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A09 | M | 45 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
A10 | M | 63 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A11 | M | 48 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A12 | M | 62 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A13 | F | 49 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A14 | M | 34 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
A15 | M | 56 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
A16 | M | 56 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
A17 | M | 58 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B01 | M | 48 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
B02 | M | 62 | Liver | Hepatocellular carcinoma | I | T2N0M0 | |
B03 | F | 42 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
B04 | M | 52 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B05 | M | 55 | Liver | Hepatocellular carcinoma | I | T2N0M0 | |
B06 | M | 45 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
B07 | M | 38 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
B08 | M | 55 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B09 | M | 45 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
B10 | M | 63 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B11 | M | 48 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B12 | M | 62 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B13 | F | 49 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B14 | M | 34 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
B15 | M | 56 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
B16 | M | 56 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
B17 | M | 58 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
C01 | M | 48 | Liver | Uninvolved liver tissue of A01/B01 | |||
C02 | M | 62 | Liver | Uninvolved liver tissue of A02/B02 | |||
C03 | F | 42 | Liver | Uninvolved liver tissue of A03/B03 | |||
C04 | M | 52 | Liver | Uninvolved liver tissue of A04/B04 | |||
C05 | M | 55 | Liver | Uninvolved liver tissue of A05/B05 | |||
C06 | M | 45 | Liver | Uninvolved liver tissue of A06/B06 | |||
C07 | M | 38 | Liver | Uninvolved liver tissue of A07/B07 | |||
C08 | M | 55 | Liver | Uninvolved liver tissue of A08/B08 | |||
C09 | M | 45 | Liver | Uninvolved liver tissue of A09/B09 | |||
C10 | M | 63 | Liver | Uninvolved liver tissue of A10/B10 | |||
C11 | M | 48 | Liver | Uninvolved liver tissue of A11/B11 | |||
C12 | M | 62 | Liver | Uninvolved liver tissue of A12/B12 | |||
C13 | F | 49 | Liver | Uninvolved liver tissue of A13/B13 | |||
C14 | M | 34 | Liver | Uninvolved liver tissue of A14/B14 | |||
C15 | M | 56 | Liver | Uninvolved liver tissue of A15/B15 | |||
C16 | M | 56 | Liver | Uninvolved liver tissue of A16/B16 | |||
C17 | M | 58 | Liver | Uninvolved liver tissue of A17/B17 | |||
D01 | M | 47 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D02 | M | 46 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D03 | M | 58 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D04 | M | 50 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D05 | M | 41 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
D06 | M | 37 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D07 | M | 34 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D08 | M | 57 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D09 | M | 30 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D10 | M | 45 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
D11 | M | 60 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
D12 | M | 43 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D13 | M | 49 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D14 | M | 54 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
D15 | M | 44 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
D16 | M | 57 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
D17 | M | 44 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
E01 | M | 47 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E02 | M | 46 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E03 | M | 58 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E04 | M | 50 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E05 | M | 41 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
E06 | M | 37 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E07 | M | 34 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E08 | M | 57 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E09 | M | 30 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E10 | M | 45 | Liver | Hepatocellular carcinoma | III | T2N0M0 | |
E11 | M | 60 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
E12 | M | 43 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E13 | M | 49 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E14 | M | 54 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
E15 | M | 44 | Liver | Hepatocellular carcinoma | II | T3N0M0 | |
E16 | M | 57 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
E17 | M | 44 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
F01 | M | 47 | Liver | Uninvolved liver tissue of D01/E01 | |||
F02 | M | 46 | Liver | Uninvolved liver tissue of D02/E02 | |||
F03 | M | 58 | Liver | Uninvolved liver tissue of D03/E03 | |||
F04 | M | 50 | Liver | Uninvolved liver tissue of D04/E04 | |||
F05 | M | 41 | Liver | Uninvolved liver tissue of D05/E05 | |||
F06 | M | 37 | Liver | Uninvolved liver tissue of D06/E06 | |||
F07 | M | 34 | Liver | Uninvolved liver tissue of D07/E07 | |||
F08 | M | 57 | Liver | Uninvolved liver tissue of D08/E08 | |||
F09 | M | 30 | Liver | Uninvolved liver tissue of D09/E09 | |||
F10 | M | 45 | Liver | Uninvolved liver tissue of D10/E10 | |||
F11 | M | 60 | Liver | Uninvolved liver tissue of D11/E11 | |||
F12 | M | 43 | Liver | Uninvolved liver tissue of D12/E12 | |||
F13 | M | 49 | Liver | Uninvolved liver tissue of D13/E13 | |||
F14 | M | 54 | Liver | Uninvolved liver tissue of D14/E14 | |||
F15 | M | 44 | Liver | Uninvolved liver tissue of D15/E15 | |||
F16 | M | 57 | Liver | Uninvolved liver tissue of D16/E16 | |||
F17 | M | 44 | Liver | Uninvolved liver tissue of D17/E17 | |||
G01 | M | 54 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G02 | F | 63 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G03 | M | 45 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G04 | M | 46 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G05 | M | 55 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
G06 | M | 54 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G07 | M | 53 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G08 | M | 64 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
G09 | M | 42 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G10 | M | 40 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G11 | M | 47 | Liver | Hepatocellular carcinoma | I | T2N0M0 | |
G12 | M | 60 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G13 | M | 51 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G14 | M | 40 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
G15 | M | 46 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G16 | M | 30 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
G17 | M | 42 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H01 | M | 54 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H02 | F | 63 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H03 | M | 45 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H04 | M | 46 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H05 | M | 55 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
H06 | M | 54 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H07 | M | 53 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H08 | M | 64 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
H09 | M | 42 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H10 | M | 40 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H11 | M | 47 | Liver | Hepatocellular carcinoma | I | T2N0M0 | |
H12 | M | 60 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H13 | M | 51 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H14 | M | 40 | Liver | Hepatocellular carcinoma | II-III | T2N0M0 | |
H15 | M | 46 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H16 | M | 30 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
H17 | M | 42 | Liver | Hepatocellular carcinoma | II | T2N0M0 | |
I01 | M | 54 | Liver | Uninvolved liver tissue of G01/H01 | |||
I02 | F | 63 | Liver | Uninvolved liver tissue of G02/H02 | |||
I03 | M | 45 | Liver | Uninvolved liver tissue of G03/H03 | |||
I04 | M | 46 | Liver | Uninvolved liver tissue of G04/H04 | |||
I05 | M | 55 | Liver | Uninvolved liver tissue of G05/H05 | |||
I06 | M | 54 | Liver | Uninvolved liver tissue of G06/H06 | |||
I07 | M | 53 | Liver | Uninvolved liver tissue of G07/H07 | |||
I08 | M | 64 | Liver | Uninvolved liver tissue of G08/H08 | |||
I09 | M | 42 | Liver | Uninvolved liver tissue of G09/H09 | |||
I10 | M | 40 | Liver | Uninvolved liver tissue of G10/H10 | |||
I11 | M | 47 | Liver | Uninvolved liver tissue of G11/H11 | |||
I12 | M | 60 | Liver | Uninvolved liver tissue of G12/H12 | |||
I13 | M | 51 | Liver | Uninvolved liver tissue of G13/H13 | |||
I14 | M | 40 | Liver | Uninvolved liver tissue of G14/H14 | |||
I15 | M | 46 | Liver | Uninvolved liver tissue of G15/H15 | |||
I16 | M | 30 | Liver | Uninvolved liver tissue of G16/H16 | |||
I17 | M | 42 | Liver | Uninvolved liver tissue of G17/H17 | |||
null |
SERVICES
CUSTOM TMA
ROUTINE PATHOLOGY
IHC / IMMUNOFLUORESCENCE
ISH / FISH
CONTRACTED SERVICES
PRIMARY IHC ANTIBODIES
PATHOLOGY FIELD
Hermatopathology
DETECTION SYSTEMS
ANCILLARIES
CONTROL TMA
bottom of page
